ActionSOM-7ULP (OEM Project – Licence)
i.MX-7ULP ARM Cortex-A7 and ARM Cortex-M4 industrial SoM computer

ActionSOM-7ULP (OEM Project – Licence)
i.MX-7ULP ARM Cortex-A7 and ARM Cortex-M4 industrial SoM computer

  • Powered by NXP i.MX 7ULP processor
  • ARM Cortex-A7 core (at speed up to 800MHz)
  • ARM Cortex-M4 core (at speed up to 200MHz)
  • 2D and 3D Graphics Processing Units (GPU)
  • Ideal solution for low cost and rich graphic systems
  • Ideal solution for Ultra Low Power Applications
  • Built-in Murata WiFi/Bluetooth
  • Built-in Ethernet Phy
  • Ideal for industrial IoT and embedded applications

CPU

CPU Name: NXP i.MX 7ULP

Application Domain: ARM Cortex-A7 core (at speed up to 800MHz)

Real Time Domain: ARM Cortex-M4 core (at speed up to 200MHz)

Memory

RAM (Application Domain): up to 1GB LPDDR3

Flash (Application Domain): up to 32GB eMMC

RAM (Real Time Domain): 256kB SRAM

Flash (Real Time Domain): up to 128Mb (16MB) QuadSPI NOR Flash

Display

Interface: MIPI DSI-2 lane display interface

GPU: 2D GPU Composition Engine, 3D GPU Low Power Single Shader

Camera: Parallel 24 bit camera input (VIU)

Networking

Ethernet: 10/100Mbit/s (integrated PHY)

Connectivity

I2C: up to 4 channels

SPI: up to 4 channels

USB: 1x USB 2.0 OTG

ADC: 2×12 ADC modules (up to 16 input channels)

Audio

Audio interfaces: I2S/SAI x3, S/PDIF Tx/Rx

Security

eFuses: Yes

RNG: Yes

Encrypt/decrypt engines: Yes

Tamper Detection: Yes

Secure RTC: Yes

Secure Boot: Yes

OS Support

Application Domain: Linux, Android

Real Time Domain: FreeRTOS

Temperature Range

Industrial: –40 to +85°C

Power Supply

Input Voltage: 5V DC

Mechanical Dimension

SOM Size: 82mm x 40mm x 4mm

Mechanical Connectors

SoM Footprint: MXM314
