HDMI interface has become the most popular video interface standard to date, and HDMI video sources are easier to come by now than ever before.

Whether you need an HDMI TFT display for your Raspberry Pi/TinkerBoard application, a Windows/Windows Embedded PC monitor, or a touch screen HMI. for your Linux or other embedded system , Powertip HDMI TFT MODULE (HTM) family product line offers a solution.

Features

  • Backlight driver and Vcom circuit on board.
  • Support USB HID for multi capacitive touch.
  • Support Brightness adjustment by touch gesture or GPIO PWM control.
  • 4 x 2.8mm Mounting Holes enabling standard M2.5 screws. Location same as Raspberry Pi and TinkerBoard.

Specification

Size InchPowertip Part No.Display FormatOutline DimensionsViewing AreaActive AreaDot PitchControllerInterfaceViewing AngelViewing DirectionBrightnessTouch Screen
4.3PH480272T005-IHC03480(RGB) x 272 dots105.5(W) * 67.2(L) * 15.76(H)97.9 (W) * 56.2 (L)95.04(W) * 53.856(L)0.198 (W) * 0.198 (L)ST7257HDMI60/60/60/606H850CTP-GG
4.3PH480272T005-IHC480(RGB) x 272 dots113.2(W) * 73.2(L) * 19.66 H)97.1 (W) * 55.9 (L)95.04(W) * 53.856(L)0.198 (W) * 0.198 (L)ST7257HDMI60/60/60/606H850CTP-OGS
5PH800480T024-IHC13800(RGB) x 480 dots121.0(W) * 75.9(L) * 15.4(H)110.0 (W) * 66.5 (L)108.0(W) * 64.8(L)0.135 (W) * 0.135 (L)NONEHDMI60/60/60/606H1000CTP-GG
5PH800480T024-IHC14800(RGB) x 480 dots121.0(W) * 75.9(L) * 24.85(H)110.0 (W) * 66.5 (L)108.0(W) * 64.8(L)0.135 (W) * 0.135 (L)NONEHDMI60/60/60/606H1000CTP-GG
7PH800480T013-IHA06800(RGB) x 480 dots164.9(W) * 100.0(L) * 18.56(H)155.08 (W) * 86.92 (L)154.08(W) * 85.92(L)0.1926 (W) * 0.179 (L)NONEHDMI50/70/70/706H1000NONE
7PH102600T009-IBC071024(RGB) x 600 dots164.9(W) * 100.0(L) * 15.7(H)155.01(W) * 86.72(L)154.21(W) * 85.92(L)0.1506 (W) * 0.1432 (L)NoneHDMI75/75/75/756H350CTP-GG
7PH800480T013-IHC08800(RGB) x 480 dots186.8(W) * 110.56(L) * 20.45(H)154.88 (W) * 86.72 (L)154.08(W) * 85.92(L)0.1926 (W) * 0.179 (L)NONEHDMI50/70/70/706H850CTP-GG
7PH800480T013-IEC02800(RGB) x 480 dots186.8(W) * 110.56(L) * 19.91(H)154.88 (W) * 86.72 (L)154.08(W) * 85.92(L)0.1926 (W) * 0.179 (L)NONEHDMI50/70/70/706H500CTP-OGS
10.1PH128800T004-ZFA011280(RGB) x 800 dots229.8(W) * 149.0(L) * 23.6(H)217.96 (W) * 136.60 (L)216.96(W) * 135.60(L)0.1695 (W) * 0.1695 (L)NONEHDMI85/85/85/85IPS500NONE
10.1PH128800T004-ZFC1280(RGB) x 800 dots254.96(W) * 173.6(L) * 26.2(H)217.96 (W) * 136.60 (L)216.96(W) * 135.60(L)0.1695 (W) * 0.1695 (L)NONEHDMI85/85/85/85IPS450CTP-GG
