3.5″ TFT Non-Touch 320×240 – PH320240T-023-I03-Q

Manufacturer: Powertip

Manufacturer Part No.: PH320240T-023-I03-Q

IHL Part No.: JXT320240T-023-I03

Screen Size: 3.5″

LCD Type: Normally white , Transmissive type

Touch Panel Type:

LCD Interface: RGB

Touch Panel Output Interface:

Touch Panel IC:

Display Resolution: 320x240px

Viewing Direction: 6 O’clock

Viewing Angle (T/B/L/R): 60/60/60/60

Outline Dimension: 76.9(W)x63.9(L)x4.75(H)mm

Active Area: 70.08(W)x52.56(L)mm

Average Brightness: 400cd/m²

Logic Supply Voltage (Typ.): 3.3V

Contrast Ratio: 600:1

Backlight: White LED
