4.3″ TFT PCAP 800×480 – PH800480T024-IHC

Manufacturer: Powertip

Manufacturer Part No.: PH800480T024-IHC

IHL Part No.: JXT800480T-024-IHC

Screen Size: 4.3″

LCD Type: a-Si TFT , Normally white, Transmissive type

Touch Panel Type: Projective Capacitive (PCAP)

LCD Interface: 24 Bits RGB

Touch Panel Output Interface:

Touch Panel IC:

Display Resolution: 800x480px

Viewing Direction: 6 O’clock

Viewing Angle (T/B/L/R): 60/60/60/60

Outline Dimension: 113.2(W)x73.2(L)x3.95(H)mm

Active Area: 95.04(W)x53.856(L)mm

Average Brightness: 850cd/m²

Logic Supply Voltage (Typ.): 3.3V

Contrast Ratio: 600

Backlight: White LED
